2027 Dirt Dog DHP12

Disc Harrows & Tillage – Pull Disc Harrow
Dirt Dog’s new Pull Disc Harrows, the DHP Series, are designed for pulverizing soil, seed bed preparation and general tillage. Solid built units available in widths of 8’, 10’ and 12’, the DHP line of disc harrows are ideally suited for use by small farmers, food plot managers, ranchers, construction crews and nursery operators. The DHP Series units share many features available on larger, more expensive models, including front-to-rear leveling, a depth control system, adjustable-gang angles, and streamlined tubular gang hangers. Multiple blade spacing options are available with your DHP Series Pull Disc harrows. Blade spacings of 7-1/2” allow for fine, finish discing needed for seedbed preparation or 9 inches for breaking up and fracturing “new ground” or a combination of the two. Six multiple blade spacing options for each model are available with your DHP Series Pull Disc Harrows; 20” or 22” notched discs at each of following spacing options: 7.5” front & rear, 9” front & rear, 9” front and 7.5”rear. High strength 1-1/8” square gang axles, combined with tough gang components, and triple lip sealed ball bearings, ensure the DHP models are ready for the toughest jobs. Put a Dirt Dog DHP disc harrow to work for you today.

Features may include:

• Triple lug tug
• 1” angle pin welded solid thru main frame for added strength
• Single wheels standard optional dual wheels available
• Sealed, self aligning bearings
• Center sweep option available
• 4” x 3” frame construction
• 5” x 3” front tube for added strength
• Massive 1” x 8” x 15” gang hangers to prevent gang twist
• Easily adjustable spring leveling system
• Jack stand standard
• Disc scrapers optional
• Available in 8’, 10’ and 12’ models
• 7 ½” and 9” spacer available
• Available in Yellow, Red, Orange, Green and Blue
